Study Guide

Configuring Microsoft Entra ID for Device Enrollment and Management

This study guide walks you through the foundational Entra ID configurations required before deploying Microsoft Intune policies. It covers:

• General device settings
• Device cleanup automation
• Enterprise State Roaming (ESR)
• Static and dynamic groups
• MDM and MAM scope configuration
• PowerShell automation using Microsoft Graph and IAM APIs

---

1. Entra ID General Device Settings

These settings define who can register or join devices, how many devices users can enroll, and whether users can retrieve BitLocker keys.

Portal Path

Microsoft Entra admin center → Devices → Overview → Device Settings

---

Key Settings Explained

1. Users may join devices to Microsoft Entra

• Set to All or Selected
• Required for Entra ID Join
• Device restrictions can be enforced later in Intune

Recommendation: Set to All

---

2. Require Multi-Factor Authentication for device join

• Leave set to No
• Use Conditional Access instead for granular control and reporting

---

3. Maximum number of devices per user

• Default: 50
• Applies to all registered devices (including personal and stale devices)
• Entra does not automatically clean stale devices

Recommendation: Leave at 50 unless you have high device volume per user.

---

4. BitLocker Recovery Key Access (Preview)

Setting:

Restrict non-admin users from recovering BitLocker keys for owned devices

• Yes → Higher security, more helpdesk tickets
• No → Easier recovery, less secure

Decision depends on security posture.

---

2. Automating Device Registration Policy with Graph

Variables

$devicequota = 50
$entraregister = 1
$entrajoin = 1
$mfa = 0
$bitlocker = "true"

---

Device Registration Policy

Uses:

PUT https://graph.microsoft.com/beta/policies/deviceRegistrationPolicy

Includes:

• Device quota
• Registration settings
• Join permissions
• MFA requirement

---

BitLocker Permission Policy

Uses:

PATCH https://graph.microsoft.com/beta/policies/authorizationPolicy/authorizationPolicy

---

3. Cleaning Up Stale Devices

Entra does not auto-remove inactive devices.

Strategy

Action	Threshold
Disable device	90 days inactive
Delete device	120 days inactive

---

Disable Devices

Filter:

• ApproximateLastSignInDateTime
• AccountEnabled = true

Patch:

{
  "accountEnabled": false
}

---

Delete Devices

Filter:

• ApproximateLastLogonTimeStamp
• AccountEnabled = false

Send:

DELETE https://graph.microsoft.com/beta/devices/{deviceId}

---

4. Enterprise State Roaming (ESR)

ESR syncs user preferences across Windows devices.

---

What ESR Syncs

Windows Settings

• Keyboard layouts
• Region settings
• Mouse configuration
• Wi-Fi profiles (WPA only)
• Web credentials
• Pen preferences

---

Microsoft Edge Settings

• Favorites
• Passwords
• Addresses
• Extensions
• Open tabs
• History

---

Enable ESR

Portal Path:
Entra ID → Devices → Device Settings → Enterprise State Roaming

Set:

Users may sync settings and app data → All

---

Automating ESR

Uses IAM API, not Graph.

Endpoint:

https://main.iam.ad.ext.azure.com/api/RoamingSettings?ESRV2=true

Requires:

• Device code authentication
• Access token creation
• REST PUT request

---

5. Creating Entra ID Static Groups

Static groups require manual membership assignment.

Portal Path

Entra ID → Groups → New Group

Settings:

• Group type: Security
• Membership type: Assigned

---

Group Capabilities

• License assignment
• Role assignment
• Nested groups
• Administrative units
• Owner delegation

---

Automating Static Group Creation

Endpoint:

POST https://graph.microsoft.com/beta/groups

Required JSON:

{
  "description": "GroupDescription",
  "displayName": "GroupName",
  "mailEnabled": false,
  "mailNickname": "groupnickname",
  "securityEnabled": true
}

---

6. Creating Entra ID Dynamic Groups

Dynamic groups automatically populate based on rules.

Membership types:

• Dynamic User
• Dynamic Device

---

Dynamic User Group – Office Licensed Users

Rule Example:

(user.assignedPlans -any
 (assignedPlan.servicePlanId -eq "ServicePlanID"
 -and assignedPlan.capabilityStatus -eq "Enabled"))

Use servicePlanId from Microsoft licensing reference list.

---

Dynamic Device Group – Autopilot Devices

Rule:

(device.devicePhysicalIDs -any (_ -contains "[ZTDID]"))

Used to target imported Autopilot devices.

---

Automating Dynamic Groups

Add to JSON:

"groupTypes": ["DynamicMembership"],
"membershipRule": "rule here",
"membershipRuleProcessingState": "On"

Submit via Graph:

POST https://graph.microsoft.com/beta/groups

---

7. Configuring MDM Scope (Critical for Intune Enrollment)

This setting determines who can enroll devices into Intune.

---

Portal Path

Entra ID → Mobility (MDM and MAM) → Microsoft Intune

---

Recommended Configuration

Setting	Value
MDM user scope	All
MAM (WIP)	None
URLs	Leave default

---

MDM vs MAM

Feature	Purpose
MDM	Corporate device enrollment
MAM	BYOD app-level management

---

8. Automating MDM Scope

Uses IAM API.

Endpoint:

https://main.iam.ad.ext.azure.com/api/MdmApplications/{policyId}

Key Settings:

"mdmAppliesTo": 2,
"mamAppliesTo": 0

Values:

• 2 = Enabled for all
• 0 = Disabled

Requires:

• Device code authentication
• Access token
• PUT request

---

Architecture Summary

Before configuring Intune policies, your Entra ID tenant should have:

• Device join enabled
• Proper device quota set
• BitLocker policy decided
• ESR configured
• Static and dynamic groups created
• MDM scope enabled
• Stale device cleanup automation in place

---

Exam Focus Areas

Expect scenario-based questions around:

• Device registration vs device join
• Conditional Access vs MFA requirement
• Graph PUT vs PATCH usage
• Dynamic group rule syntax
• ServicePlanId filtering
• Autopilot device queries
• IAM API vs Graph API usage
• Stale device cleanup logic

---

Practical Lab Checklist

✔ Enable Entra device join
✔ Configure device quota
✔ Set BitLocker retrieval preference
✔ Enable ESR
✔ Create static security group
✔ Create dynamic Office user group
✔ Create dynamic Autopilot device group
✔ Configure MDM user scope
✔ Automate settings with Graph

---
